TRUX-iMX8MMini-Q01

CPU Name: NXP i.MX 8M Mini
Architecture: Quad Core ARM Cortex-A53@1.5GHz speed, Cortex-M4
RAM: 1GB- 4GB LPDDR4
Memory: 8GB- 32GB eMMC
OS Support: Linux 5.4.1, Android 11

Categories: NXP i.MX8, System On Module

Contact Now Download Brochure Documents

Compare to other products

Description

The TRUX-iMX8MMini-Q01, computing module is based on an NXP i.MX 8M Mini Quad processor implementing ARM Cortex–A53 up to 1.8GHz and Cortex-M4, supporting up to 400MHz speed for many industrial, embedded consumer, and IOT applications.

System on module offers an ideal solution for embedded systems that require high-end multimedia applications in a small form factor, as well as portable and battery-operated products.

TRUX-iMX8MMini-Q01 is part of the iMX8 SOM family, which supports a pin2pin scalable option with
TRUX-iMX8M-Q01, TRUX-iMX8MPlus-Q01 system on module.

System On Module is aimed to offer applications such as Digital Media Adaptors, HD Digital signage, Industrial HMI, Building Automation, Imaging and scanning, Audio/Video Streaming devices, and Machine Vision applications.

Specificaiton

Features:	CPU: 1.8 GHz Quad CortexTM-A53 NXP i.MX8M Mini Controller : Arm CortexTM-M4F 3D GPU (1x shader, OpenGL® ES 2.0) 2D GPU, Arm® Trustzone®	Peripherals:
Memory:	RAM: LPDDR4 (1GB – 4GB) Flash: eMMC (8 GB – 32 GB)	MIPICSIx1 NAND x1 eMMCx1 Gbit Ethernet x 1 PCI Express x 1 (Gen 2.0) DSIx1 I2Cx4 SPIx3 JTAGx1 USB 2.0 (OTG) x 2 SD/MMCx3UARTx4 GPIOs Boot Mode Signals Digital Audio serial Interface: I2S (SAI), S/PDIF
Multimedia:	3D: GPU(1 x shader, OpenGL® ES 2.0) 2D GPU Video Encode/Decode: 1080p60 HEVC/H.265,H.264 VPB Encoder/-Decoder Camera Interfaces: 1 x MIPI-CSI
Security:	Crypto authentication
Security:	HDMI: V2.0a up to 4Kp60 DSI: MIPI-DSI 1920×1080 24-bit Touch controller: Resistive, Capacitive
Connectivity:	Ethernet: 10/100/1000 Mbps with AVB and EEE Wi-Fi: Certified 802.11 ac/a/b/g/n Bluetooth: 4.2 / BLE
Power Supply:	3.3V to 5V
Supported temperature:	0°C to +70°C Commercial -40°C to +85°C Industrial
OS support:	Linux, Android
Dimension:	55.1 mm x 30.2 mm
Peripherals:	CSI x2 NAND x1 eMMC x 1 Gbit Ethernet x 1 PCI Express x 2 (Gen 2.0) DSI x1 HDMI x1 I2C x3 SPI x3 JTAGx1 USB 3.0/2.0 (OTG) x 2 SD/MMCx1 UARTx4 GPIOs Boot Mode Signals Digital Audio serial interface : I2S (SAI), S/PDIF

Ordering Info

Part Number	TRUX- iMX8MMini-Q01- D1G-E8G-C	TRUX- iMX8MMini-Q01- D1G-E16G-C	TRUX- iMX8MMini-Q01-D4G-E16G- C	TRUX- iMX8MMini-Q01-D4G- E32G-C
Clock Speed	1800 MHz	1800 MHz	1800 MHz	1800 MHz
RAM	1 GB	1 GB	4 GB	4 GB
Flash	8 GB	16 GB	16 GB	32 GB
Operating temperature	0°C to +70°C	0°C to +70°C	0°C to +70°C	0°C to +70°C

Part Number	TRUX-iMX8MMini-Q01-D1G-E8G-I	TRUX-iMX8MMini-Q01-D1G-E16G-I	TRUX-iMX8MMini-Q01-D4G-E16G-I	TRUX-iMX8MMini-Q01-D4G-E32G-I
Clock Speed	1600 MHz	1600 MHz	1600 MHz	1600 MHz
RAM	1 GB	1 GB	4 GB	4 GB
Flash	8 GB	16 GB	16 GB	32 GB
Operating temperature	-40°C to +85°C	-40°C to +85°C	-40°C to +85°C	-40°C to +85°C
